for cover kit 3-gang, ref.-no.: .. 4093 TSA .. in the LS range
can be extended by means of a push-button extension module, ref.-no.: 409.. TSEM
Numatytoji paskirtis- Operation of loads, e.g. light on/off, dimming, blinds up/down, brightness values, temperatures, calling up and saving light scenes, etc.
- Measurement and feedback control of the room temperature
- Montavimas montažinėje dėžutėje, kurios matmenys atitinka DIN 49073 standartą
Produkto savybėsAll buttons can be assigned with push-button sensor functions or functions for controller operation.
- KNX medium: TP 256
- Four red status LEDs
- One blue operation LED as orientation light and to indicate the programming status
- Integrated bus coupling unit
- Connection for a push-button extension module, 1-4 gang
- Integrated temperature sensor
- Room temperature control with setpoint specification
- Display of room or set temperature
- Display of outdoor temperature – with external sensor, e.g. weather station
- Display of time, in conjunction with KNX time encoder
- Push-button functions switching, dimming, controlling blinds, value transmitter, calling up light scenes etc.
- Button function or rocker function, vertical or horizontal
- Fan coil application with up to 8 fan levels and auto function
- KNX Data Secure compatible with ETS 5.7.7 or ETS 6.3.0 or higher
- Can be updated with the ETS Service App
Accessories:Screw assortment for sensors, ref.-no.: S-BOX TSM RT ZN
