Converter sun / twilight
17 USD REG
rail mounting device, 1 rail unit
for connection of sun sensor ref.-no.: 17 S
Product characteristics
for connection of sun sensor ref.-no.: 17 S
Product characteristics
- Adjuster for threshold value "brightness"
- Adjuster for threshold value "twilight"
- Adjuster for switch-on/switch-off delay
- Operating mode switch (2-second pulse or permanent)
- LED "B": brightness exceeded
- LED "D": twilight below threshold
- LED "14": status indication relay output 14 (UP)
- LED "24": status indication relay output 24 (DOWN)
- Automatic slat adjusting time
- Integrated power supply for sensors
- Group control with universal blinds insert
- Integration into JUNG HOME via binary inputs
Read less...
Read more...
new
Information
| Article number: | 17 USD REG |
|---|---|
| EAN/GTIN: | 4011377360785 |
Read less...
Read more...
Technical data
| Rated voltage: | AC 230 V ~ |
| Mains frequency: | 50/60 Hz |
| Power consumption: | 0.6 W |
| Sun (brightness) | |
| Measuring range: | 20,000 ... 100,000 lx |
| Switching hysteresis: | 40 % |
| Sun (twilight) | |
| Measuring range: | 1 ... 70 lx |
| Switching hysteresis: | 20 % |
| Switch-on / switch-off delay: | OFF or 1 … 15 min |
| Motor running time: | 90 s (1 … 240 s adjustable) |
| Relay switching pause: | 0.6 s |
| Relay output: | 2 floating NO contacts, 10 A / 250 V ~ |
| Power supply for sensor: | DC 3.3 V (PELV) |
| Connection | |
| Connection mode: | screw terminals |
| single wire: | 1 x 0.5 ... 4.0 mm² 2 x 0.5 ... 2.5 mm² |
| stranded without ferrule: | 1 x 0.5 ... 4.0 mm² 2 x 0.5 ... 2.5 mm² |
| stranded with ferrule: | 1 x 0.5 ... 4.0 mm² 2 x 0.5 ... 1.5 mm² |
| Mounting width: | 18 mm (1 rail unit) |
| Ambient temperature: | −10 ... +45 °C |
Read less...
Read more...
Downloads
| Operating instructions | |
|---|---|
| Product documentation | |
| Tendering text | |
| EC Declaration of Conformity | |
| Article datasheet |
Read less...
Read more...
Logistic
| Single item | |
|---|---|
| Packaging unit | 1 pc. |
| Weight | 0.063 KG |
| Length | 89 MM |
| Height | 59 MM |
| Width | 18 MM |
| Carton | |
| Packaging unit | 1 pc. |
| Weight | 0.098 KG |
| Length | 95 MM |
| Height | 46 MM |
| Width | 95 MM |
