Converter sun / wind
17 USW REG
17 USW REG
new
Or search directly in a category
| Article number: | 17 USW REG |
|---|---|
| EAN/GTIN: | 4011377360761 |
| Rated voltage: | AC 230 V ~ |
| Mains frequency: | 50/60 Hz |
| Power consumption: | 0.66 W |
| Wind | |
| Measuring range: | 10 ... 70 km/h |
| Switching hysteresis: | 25 % |
| Switch-on delay: | 1 … 15 s (dynamic) |
| Sun (brightness) | |
| Measuring range: | 20,000 ... 100,000 lx |
| Switching hysteresis: | 40 % |
| Sun (twilight) | |
| Measuring range: | 1 ... 70 lx |
| Switching hysteresis: | 20 % |
| Switch-on delay "sun": | 10 min (1 … 60 min adjustable) |
| Motor running time: | 90 s (1 … 240 s adjustable) |
| Relay switching pause: | 0.6 s |
| Relay output: | 2 floating NO contacts, 10 A / 250 V ~ |
| Slat adjusting time: | OFF or 0.1 … 1.3 s |
| Power supply for sensor: | DC 3.3 V (PELV) |
| Connection | |
| Connection mode: | screw terminals |
| single wire: | 1 x 0.5 ... 4.0 mm² 2 x 0.5 ... 2.5 mm² |
| stranded without ferrule: | 1 x 0.5 ... 4.0 mm² 2 x 0.5 ... 2.5 mm² |
| stranded with ferrule: | 1 x 0.5 ... 4.0 mm² 2 x 0.5 ... 1.5 mm² |
| Mounting width: | 18 mm (1 rail unit) |
| Ambient temperature: | −10 ... +45 °C |
| Operating instructions | |
|---|---|
| Product documentation | |
| Tendering text | |
| EC Declaration of Conformity | |
| Article datasheet |
| Single item | |
|---|---|
| Packaging unit | 1 pc. |
| Weight | 0.068 KG |
| Length | 89 MM |
| Height | 59 MM |
| Width | 18 MM |
| Carton | |
| Packaging unit | 1 pc. |
| Weight | 0.104 KG |
| Length | 95 MM |
| Height | 46 MM |
| Width | 95 MM |
